①A2-11 high-rigidity spindle and bearing are lubricated by the hydraulicoil.
②Integrated servo hydraulic tool rest,with more compact structure,and more stable and reliable mechanical precision
③The guide rail ofthe machine tool body is designed with high and low rails,the machine tool body is cast as a whole,and the intemal stressis eliminated through multichannel aging and heat treatment process,so that the machine tool can maintain the optimum precisionand rigidty for a long time.
④For the hydraulic test and adjustment,the panelis installed in front,with mechanical rotation operation,and it is easy to monitor and adjust the hydraulic system pressure from the front of the machine.
⑤The X asis of the machine tool adopts the inclined design of 30°,RG45 roller linear guide rail and RG40 roller screw,with the advantages of strong ability to offset heavy cutting vibration and high precision.
| Item | Specification | LA600CT-800 | LA600DT-800 | |
| Machining capacity | Tool rest specification | 125-12-32 | 125-12-32 | |
| Maximum rotating diameter | mm | 700 | 700 | |
| Standard machining diameter | mm | 300 | 300 | |
| Maximum machining diameter | mm | 600 | 600 | |
| Maximum machining length | mm | 750 | 750 | |
| Machining diameter of bar | mm | 84 | 95 | |
| Movement | X-axis movement | mm | 320 | 320 |
| Z-axis movement | mm | 800 | 800 | |
| Spindle | Rotating speed | r/min | 1200 | 1200 |
| Minimum indexing angle CS axiS control) | deg | - | - | |
| Spindle end (nominal No.) | - | A2-8 | A2-11 | |
| Through-hole diameter | mm | 86 | 105 | |
| Inner diameter of bearing | mm | 130 | 160 | |
Tool rest | Tool rest form | Tool rest form | Direct-mounted | Direct-mounted |
| Tool clamping quantity | PcS. | 12 | 12 | |
| Height of rectangular cutter handle | mm | 32 | 32 | |
| Diameter of boring bar handle | mm | 50 | 50 | |
| Tool magazine/ power head | Specification | - | BT40 | BT40 |
| Station | T | 8T | 8T | |
| Tool changing power | kw | 1.1KW contracting brake | .1KW contracting brake | |
| Sub- spindle | Power head | - | BT40 | BT40 |
| Power of power head | kw | 5.5KW | 5.5KW | |
| Feed speed | Fast feed speed | m/min | X:24/Z:30/ | X:24/Z:30/ |
| Motor | Spindle motor | kW | 15 | 15 |
| Rotating tool motor (15min/continuous) | kW | - | - | |
| Feed shaft motor | NM | X:11/Z:11 | X:11/Z:11 | |
| Hydraulic pump motor | kW | 2.2 | 2.2 | |
| Motor for cutting fluid pump | kW | 0.55 | 0.55 | |
| Required power supply | Power supply (three-phase) | V | 380±10% | 380±10% |
| Fuel tank capacity | Used for the hydraulic device | L | 45 | 45 |
| Used for the lubricating oil | L | 3 | 3 | |
| Used for the cutting fluid | L | 200 | 200 | |
| Machine tool volume | Height of machine tool | mm | 1800 | 1800 |
| Height from ground to the spindle center line | mm | 1060 | 1060 | |
| Floor area (standard specification | mm x mm | 3330x 2210 | 3330x2210 | |
| Weight of Machine Tool | kg | 5000 | 5000 | |
